Create a Basketball Free Throw Game with Unity

by
Difficulty:IntermediateLength:LongLanguages:
Final product image
What You'll Be Creating

Introduction

In this tutorial, you'll learn how to create a mobile 3D game using C# and Unity. The objective of the game is to score as many points as possible. You'll learn the following aspects of Unity game development:

  • Setting up a 3D project in Unity
  • Implementing tap controls
  • Integrating physics
  • Creating Prefabs

1. Create a New Unity Project

Open Unity and select New Project from the File menu to open the new project dialog. Tell Unity where you want to save the project and set the Set up defaults for: menu to 3D.


2. Build Settings

In the next step, you're presented with Unity's user interface. Set the project up for mobile development by choosing Build Settings from the File menu and select your preferred platform. I've chosen Android for this tutorial.


3. Devices

The first thing we need to do after selecting the platform we're targeting is choosing the size of artwork that we'll use in the game. I've listed the most important devices for each platform below and included the device's screen resolution and pixel density.

iOS

  • iPad: 1024px x 768px
  • iPad Retina: 2048px x 1536px
  • 3.5" iPhone/iPod Touch: 320px x 480px
  • 3.5" iPhone/iPod Retina: 960px x 640px
  • 4" iPhone/iPod Touch: 1136px x 640px

Android

Because Android is an open platform, there are many different devices, screen resolutions, and pixel densities. A few of the more common ones are listed below.

  • Asus Nexus 7 Tablet: 800px x 1280px, 216ppi
  • Motorola Droid X: 854px x 480px, 228ppi
  • Samsung Galaxy S3: 720px x 1280px, 306ppi

Windows Phone

  • Nokia Lumia 520: 400px x 800px, 233ppi
  • Nokia Lumia 1520: 1080px x 1920px, 367ppi

BlackBerry

  • Blackberry Z10: 720px x 1280px, 355ppi

Remember that the code used for this tutorial can be used to target any of the above platforms.

4. Export Graphics

Depending on the devices you're targeting, you may need to convert the artwork for the game to the recommended size and resolution. You can do this in your favorite image editor. I've used the Adjust Size... function under the Tools menu in OS X's Preview application.


5. Unity User Interface

Before we get started, make sure to click the 3D button in the Scene panel. You can also modify the resolution that's being displayed in the Game panel.


6. Game Interface

The interface of our game will be straightforward. The above screenshot gives you an idea of the artwork we'll be using and how the game's interface will end up looking. You can find the artwork and additional resources in the source files of this tutorial.


7. Programming Language

You can use one of three programming languages when using Unity, C#, UnityScript, a variation of JavaScript, and Boo. Each programming language has its pros and cons, and it's up to you to decide which one you prefer. My personal preference goes to the C# programming language so that's the language I'll be using in this tutorial.

If you decide to use another programming language, then make sure to take a look at Unity's Script Reference for examples.


8. Sound Effects

I'll use a number of sounds to improve the audial experience of the game. The sound effects used in this tutorial were obtained from as3sfxr and Soungle.


9. 3D Models

To create our game, we first need to get our 3D models. I recommend 3Docean for high quality models, textures, and more, but if you're testing or still learning then free models may be a good place to start.

The models in this tutorial were downloaded from SketchUp 3D Warehouse where you can find a good variety of models of all kinds.

Because Unity doesn't recognize the SketchUp file format, we need to convert SketchUp files to a file format Unity can import. Start by downloading the free version of  SketchUp, SketchUp Make.

Open your 3D model in SketchUp Make and go select Export > 3D Model from the File menu and choose Collada (*.dae) from the list of options.

Choose a name, select a directory, and click Export. A file and a folder for the 3D model will be created. The file contains the 3D object data and the folder the textures used by the model. You can now import the model into Unity as explained in the next step.


10. Import Assets

Before we start coding, we need to add our assets to the Unity project. You can do this one of several ways:

  • Select Import New Asset from the Assets menu.
  • Add the items to the assets folder of your project.
  • Drag and drop the assets in the project window.

After completing this step, you should see the assets in your project's Assets folder in the Project panel.


11. Create Scene

We're ready to create the scene of our game by dragging objects to the Hierarchy or Scene panel.


12. 2D Background

Start by dragging and dropping the background into the Hierarchy panel. It should automatically appear in the Scene panel. Adjust the Transform values in the Inspector as shown in the next screenshot.


13. Hoop

The objective of the game is throw the ball through the hoop. Drag it from the Assets panel to the Scene and change its Transform properties as shown in the below screenshot.


14. Light

As you may have noticed, the basketball hoop is a bit too dark. To fix this, we need to add a Light to our scene. Go to GameObject > Create Other and select Directional Light. This will create an object that will produce a beam of light. Change its Transform values as shown in the next screenshot so that it illuminates the basketball hoop.


15. Hoop Collider

With the basketball hoop properly lighted, its time to add a collider so the ball doesn't go through when it hits the white area.

Click the Add Component button in the Inspector panel, select Physics > Box Collider, and change its values as shown in the next screenshot.

You'll see a green border around the basketball hoop in the Scene panel representing the box collider we just added.


16. Bounce Physics Material

If we were throw a ball at the basketball hoop, it would be stopped by the box collider, but it would stop without bouncing like you'd expect it to in the real world. To remedy this we need a Physics Material.

After selecting Create > Physics Material from the Assets menu, you should see it appear in the Assets panel. I changed the name to BounceMaterial.

Change its properties in the Inspector panel to match the ones in this below screenshot.

Next, select the box collider of the basketball hoop and click on the little dot to the right of the Material text, a window should appear where you can select the physics material.


17. Basket Collider

We'll use another collider to detect when the ball passes through the hoop. This should be a trigger collider to make sure it detects the collision without interacting with the physics body.

Create a new collider for the hoop as shown in step 15 and update its values as shown in the next screenshot.

This will place the collider below the ring where the ball can't go back upwards, meaning that a basket has been made. Be sure to check the Is Trigger checkbox to mark it as a trigger collider.


18. Ring Mesh Collider

Time to add a collider to the ring itself. Because we need the ball to pass through the center of the ring, we can't have a sphere or box collider, instead we'll use a Mesh Collider.

A Mesh Collider allows us to use the shape of the 3D object as a collider. As the documentation states the Mesh Collider builds its collision representation from the mesh attached to the GameObject.

Select the hoop from the Hierarchy panel, click on the triangle on its left to expand its hierarchy, expand group_17, and select the element named Ring.

Add a collider as we saw in step 15, but make sure to select Mesh Collider. Unity will then automatically detect the shape of the model and create a collider for it.


19. Hoop Sound

To play a sound when the ball hits the hoop, we first need to attach it. Select it from the Hierarchy or Scene view, click the Add Component button in the Inspector panel, and select Audio Source in the Audio section.

Uncheck Play on Awake and click the little dot on the right, below the gear icon, to select the sound you want to play.


20. Ball

Let's now focus on the basketball. Drag it from the Assets folder and place it in the scene. Don't worry about the ball's position for now, because we'll convert it to a Prefab later.

To make the ball detect when it hits the hoop, we need to add a component, a Sphere Collider to be precise. Select the ball in the scene, open the Inspector panel, and click Add Component. From the list of components, select Sphere Collider from the Physics section and update its properties as shown below.


21. Ball RigidBody

To detect a collision with the basketball, at least one of the colliding objects needs to have a RigidBody component attached to it. To add one to the ball, select Add Component in the Inspector panel, and choose Physics > RigidBody.

Leave the settings at their defaults and drag the ball from the Hierarchy panel to the Assets panel to convert it to a Prefab.


22. Hoop Sprite

To represent the baskets already made by the player, we use a 2D version of the basketball hoop. Drag it from the Assets panel and place it on the scene as shown below.


23. Score Text

Below the 2D hoop, we display the number of baskets the player has scored so far. Select GameObject > Create Other > GUI Text to create a text object, place it at the bottom of the basketball hoop, and change the text in the Hierarchy panel to 0.

You can embed a custom font by importing it in the Assets folder and changing the Font property of the text in the Inspector.

24. Force Meter

The force meter is a bar that will show the force used to shoot the ball. This will add another level of difficulty to the game. Drag the sprites for the force meter from the Assets panel to the Scene and position them as shown in the screenshot below.


25. Ball Sprite

We also add an indicator to the interface showing how many shots the player has left. To complete this step, follow the same steps we used to display the player's current score.


26. Basket Script

It's finally time to write some code. The first script that we'll create is the Basket script that checks if the ball passes through the ring or hits the board.

Select the hoop and click the Add Component button in the Inspector panel. Select New Script and name it Basket. Don't forget to change the language to C#. Open the newly created file and add the following code snippet.

In this script, we set two public variables that represent objects on the Scene and in the Assets folder. Go back to the editor and click the little dot on the right of the variables to select the values described in the comments.

We play a sound when the ball hits the basketball hoop and check if the ball passes through the ring. The Parse method will convert the text from the GUI Text game object to a  number so we can increment the score and then set it again as text using toString. At the end, we play the basket sound.

27. Shoot Script

The Shoot class handles the rest of the game interaction. We'll break the script's contents down to make it easier to digest.

Start by selecting the Camera and click the Add Component button in the Inspector panel. Select New Script and name it Shoot.

28. Variables

In the next code snippet, I've listed the variables that we'll use. Read the comments in the code snippet for clarification.


29. Increase Gravity

Next, we create the Start method in which we set the gravity force to -20 to make the ball drop faster.


30. Force Meter Behavior

To handle interactions with the physics engine, we implement the FixedUpdate method. The difference between this method and the regular Update method is that FixedUpdate runs based on physics steps instead of every frame, which might cause problems if the device is slow due to a shortage of memory, for example.

In the FixedUpdate method, we move the arrow of the force meter using the right variable to detect when to reverse the arrow's movement.

31. Shoot Ball

The basketball is thrown when the player taps the screen. Whenever the screen is tapped, we first check if there's already a ball in the air and if the player has shots available. If these requirements are met, we update the values, create a new instance of the ball, and throw it using the addForce method.


32. Remove Ball

In the following code block, we test if the ball reaches the floor and remove when it does. We also prepare for the next throw by resetting the variables.


33. Check Available Shots

After removing the ball, we verify that the player has shots left. If this isn't the case, then we end the game and call restart.

34. restart

The restart method runs two seconds after the player runs out of shots, restarting the game by invoking LoadLevel.


35. Testing

It's time to test the game. Press Command-P to play the game in Unity. If everything works as expected, then you're ready for the final steps.


36. Player Settings

When you're happy with your game, it's time to select Build Settings from the File menu and click the Player Settings button. This should bring up the Player Settings in the Inspector panel where you can set the parameters for your application.

The settings are application and include the creator or company, application resolution and display mode, rendering mode, device compatibility, etc. The settings will differ depending on the platform and devices your application is targeting and also keep the requirements of store you're publishing on in mind.


37. Icons and Splash Images

Using the artwork you created earlier, you can now create a nice icon and a splash image for your game. Unity shows you the required sizes, which depend on the platform you're building for.

38. Build and Play


Once your project is properly configured, it's time to revisit the Build Settings and click the Build Button. That's all it takes to build your game for testing and/or distribution.

Conclusion

In this tutorial, we've learned about 3D models, mesh colliders, physics materials, collision detection, and other aspects of Unity game development. I encourage you to experiment with the result and customize the game to make it your own. I hope you liked this tutorial and found it helpful.
